API 5CT ERW Casing Pipes, OCTG Casing
Qauv | API 5 CT |
Daim ntawv pov thawj | API |
Qib | H40/ L80/ R95/ N80-1/ N80Q/ C90/ T95/ P110 |
Tawm Dia | 1.9"-4 1/2" |
Phab ntsa Thickness | 3. 18 - 16 mm |
Ntev | R1/ R2/ R3 |
Xaus | BTC, UN, EUE, hwm kawg |
Kev siv | Roj thiab Roj |
Nto | Liab, Dub, Varnish, Roj, 3PE, thiab lwm yam |
Specification
OCTG txhais tau hais tias Roj Lub Tebchaws Tubular Cov Khoom Muag, uas yog hais txog cov hlau siv hauv cov roj thiab cov roj rho tawm thiab cov txheej txheem tsim khoom, suav nrog Laum yeeb nkab, Casing, Tubing, Couplings, Txuas thiab Accessories, rau kev lag luam roj thiab roj hauv av thiab sab nrauv.
API 5CT yog cov qauv kev qhia tshwj xeeb rau steel casing thiab tubing kav siv rau cov roj qhov dej hauv kev lag luam roj av thiab cov nkev. Casing thiab Tubing yog ib hom OCTG yeeb nkab.
Tubing yog siv los nqa roj av los ntawm lub qhov dej tob mus rau qhov chaw. Qhov no yog theem peb ntawm cov txheej txheem wellbore. Roj thiab roj qee zaus nws tus kheej nce mus rau saum npoo; Txawm li cas los xij, cov twj tso kua mis feem ntau yuav tsum tau nqa cov kua dej rau saum npoo. Dhau li ntawm 4 1/2-inch txoj kab uas hla, tubing feem ntau me me nyob rau hauv txoj kab uas hla tshaj casing. Yog li ntawd, tubing yuav tsum tau txuas rau cov qauv kev txhawb nqa sab nraud, xws li lub rig lossis lub platform, txhawm rau tiv thaiv kev sib tsoo vim qhov sib txawv ntawm qhov sib txawv.
Piv txwv Loj
Nco tseg: Qee qhov tshwj xeeb tseem ceeb tau qhia hauv qab no, thov hu rau peb kom paub meej ntxiv.
Sab nraud txoj kab uas hla (O.D) | TUB NTXHAIS (TK) | Qhov hnyav | Xaus daim ntawv ua tiav | ||||||||
Qib | |||||||||||
Ntiv | mm | Ntiv | mm | TBG | UPTBG | J55 | L80-1 | N80 | C90 | T95 | P110 |
1.900" | 48.26 | 0.145 | 3.68 | 2.75 | 2.9 | PNUI | PNUI | PNUI | PNUI | PNUI | - |
2 3/8" | 60.32 | 0.254 | 6.45 | 5.8 | 5.95 | - | PNU | PNU | PNU | PNU | PNU |
2 7/8" | 73.02 | 0.308 | 7.82 | 8.6 | 8.7 | - | PNU | PNU | PNU | PNU | PNU |
3 1/2" | 88.9 | 0.289 | 7.34 | 10.2 | - | PN | PN | PN | PN | PN | PNU |
4" | 101.6 | 0.262 | 6.65 | 10.7 | 11 | PU | PU | PU | PU | PU | - |
4 1/2" | 114.3 | 0.271 | 6.88 | 12.6 | 12.75 | PNU | PNU | PNU | PNU | PNU | - |
One-stop kev pab cuam los pab koj kev yuav khoom
Baolai Group tseem muab kev pabcuam thiab kev txhawb nqa tom qab koj yuav khoom. Txhawm rau txuag koj lub sijhawm, peb muab ntau yam kev pabcuam ntxiv rau koj xws li kev ua haujlwm, kev tswj xyuas kev thauj mus los thiab kev sim.
Kev Pabcuam:
· √OEM & ODM
· √ Cov txheej txheem tiv thaiv
· √Saw thiab nplaim taws txiav
√ Beveling, Threading thiab Grooving
· √ Xav paub ntau ntxiv, thov hu rau peb pab neeg pabcuam.
Ntau tshaj li cov chaw tsim khoom, peb muab ib qho kev daws teeb meem rau koj lub lag luam. Hu rau tam sim no!
