ASTM A795 ERW Cov Hluav Taws Xob Hluav Taws Xob
video

ASTM A795 ERW Cov Hluav Taws Xob Hluav Taws Xob

ASTM A795 ERW steel yeeb nkab yog tsim los siv rau hauv dej raws li kev tiv thaiv hluav taws rau cov dej xa dej los yog daim ntawv thov valve trim, xws li ntub, qhuav, preaction, lossis deluge sprinkler systems.
Xa kev nug
Khoom Taw qhia

Qauv

ASTM A795 / UL 852 Txheem:

Daim ntawv pov thawj

UL / FM

Qib

Gr.A/B

Tawm Dia

1/2" - 14" (DN{3}} DN350)

Phab ntsa Thickness

2 11-7.80 hli

Ntev

5.8M / 6M / 12M lossis Customized

Xaus

Plain / Beveled / Yob zawj / NPT / BSPT

Nto

Liab / Dub / Liab epoxy lossis polyester / Galvanized



Specification

ASTM A795 ERW steel yeeb nkab yog tsim los siv rau hauv dej raws li kev tiv thaiv hluav taws rau cov dej xa dej los yog daim ntawv thov valve trim, xws li ntub, qhuav, preaction, lossis deluge sprinkler systems.



1



Qhov zoo:

Flexibility thiab yooj yim ntawm kev ua haujlwm

Muaj lub cib fim txaus los koom nrog kev cog qoob loo yav tom ntej

Ib qho yooj yim cog foundation

Lub sij hawm hloov ceev mus rau lwm txoj kab

Xim Xaiv: · liab · xiav · ntsuab · dub · dawb


Piv txwv Loj

Nco tseg: Qee qhov tshwj xeeb tseem ceeb tau qhia hauv qab no, thov hu rau peb kom paub meej ntxiv.



Sab nraud txoj kab uas hla
(O.D)

TUB NTXHAIS

Kuaj Siab




DN

hauv.

mm

mm

Mpa

Sch10

25

32

40

50

65

80

100

125

150

1"

33.4

2.77

4.8

1-1/4"

42.2

2.77

6.9



1-1/2"

48.3

2.77

6.9



2"

60.3

2.77

6.9



2-1/2"

73

3.05

6.9



3"

88.9

3.05

6.9



4"

114.3

3.05

8.3



5"

141.3

3.40

8.3



6"

168.3

3.40

6.9



Sch40

25

32

40

50

65

80

100

125

150

1"

33.4

3.38

4.

1-1/4"

42.2

3.56

6.9



1-1/2"

48.3


6.9



2"

60.3

3.91

6.9



2-1/2"

73

5.16

6.9



3"

88.9

5.49

6.9



4"

114.3

6.02

8.3



5"

141.3

6.55

8.3



6"

168.3

7.11

8.3





One-stop kev pab cuam los pab koj kev yuav khoom

Baolai Group tseem muab kev pabcuam thiab kev txhawb nqa tom qab koj yuav khoom. Txhawm rau txuag koj lub sijhawm, peb muab ntau yam kev pabcuam ntxiv rau koj xws li kev ua haujlwm, kev tswj xyuas kev thauj mus los thiab kev sim.


Kev Pabcuam:

· √OEM & ODM

· √ Cov txheej txheem tiv thaiv

· √Saw thiab nplaim taws txiav

√ Beveling, Threading thiab Grooving

· √ Yog xav paub ntxiv, thov hu rau peb pab neeg pabcuam.

Ntau tshaj li cov chaw tsim khoom, peb muab ib qho kev daws teeb meem rau koj lub lag luam. Hu rau tam sim no!
